Elevator Spider Gear in NYC Highrise

20, Gray Iron
Serial # 14661-001
Heat # 28297 D
Casting Wt.: 420 lbs.

Actual Test Results:
Ultimate: 31,915 psi
Brinell: 143

Arbor Press for a Bearing Manufacturer

Class 30, Gray Iron
Serial # 14656-014
Heat # 29797 E
Casting Wt.: 150 lbs.

Actual Test Results:
Ultimate: 34,630 psi
Brinell: 183

Air Conditioner Housing on the Queen Elizabeth II

Class 40, Gray Iron
Serial # 14380-031
Heat # 28097 G
Casting Wt.:156 lbs.

Actual Test Results:
Ultimate: 47,241 psi
Brinell: 228

Plastic Extruder Throat for a Toy Manufacturer

Class 35, Gray Iron
Serial # 14404-002
Heat # 28397 H
Casting Wt.: 765 lbs.

Actual Test Results:
Ultimate: 38,770 psi
Brinell: 179

40 ft. Racing Sailboat Keel

80-55-06, Ductile Iron
Serial # 14753-002
Heat # 32197 A
Casting Wt.: 1720 lbs.

Actual test results:
Ultimate: 102,301 psi
Yield: 61,185 psi
Elongation: 7%
Brinell: 217

Pump Housing for a Copper Mine in Utah

65-45-12, Ductile Iron
Serial # 12060-021
Heat # 01907 A
Casting Wt.: 1920 lbs.

Actual Test Results:
Ultimate: 73,000 psi
Yield: 51,610 psi
Elongation: 16%
Brinell: 187

Saddle for Cylindrical Shaft Grinder

80-60-03, Ductile Iron
Serial # 14592-004
Heat # 30397 E
Casting Wt.: 1480 lbs.

Actual Test Results:
Ultimate: 86,407 psi
Yield: 60,384 psi
Elongation: 4%
Brinell: 143

Plastic Filter Body for 2-Liter Bottle Recycler

80-55-06, Ductile Iron
Serial # 14103-010
Heat # 20397 A
Casting Wt.: 440 lbs.

Actual Test Results:
Ultimate: 113,205 psi
Yield: 61,647 psi
Elongation: 7%
Brinell: 212
